Author: P.S. Gill

Brand: S.K. KATARIA & SONS

Edition: 2013

Binding: paperback

Number Of Pages: 690

Release Date: 01-01-2013

Part Number: 20695

Details: Table of Contents: Manual Drawing Instruments Conventional Lines, Drawing Sheets-Their Layout and Planning Technical Lettering, Dimensioning and Geometrical Constructions Scales Loci and Mechanisms Loci-conic Sections Cycloidal and Spiral Curves Helix, Helical Springs and Screw Threads Projections of Points Projections of Lines Projections of Planes and Laminae Auxiliary Planes and Views Projections of Solids Sections of Solids Developments of Surfaces Intersections of Surfaces Isometric Projection Theory of Orthographic Projections Reading a Drawing-Missing Lines and Missing Views Oblique Projections Perspective Projections Index

EAN: 9789350143155

Package Dimensions: 9.4 x 7.2 x 1.2 inches

Languages: English
